Aluminium Evolution Canopy
A versatile, high-performance cover system designed for residential and commercial applications, engineered and perfected over 30 years of manufacturing expertise.
Dual-Purpose Design
The Evolution Canopy works equally well as a protective carport or elegant patio cover canopy, allowing you to adapt your space to your needs. Whether you're protecting vehicles, creating outdoor living areas, or shielding sensitive equipment, this system delivers.
Built to Last
Proven Heritage Manufactured for over 30 years, the Evolution Canopy represents three decades of refinement and customer trust.
Durable Construction Our all-aConstructionme features maintenance-free, powder-coated construction that resists rust, corrosion, and fading. No painting or regular upkeep is required.
Smart Drainage The integral eaves beam and box gutter system efficiently channels water away through supporting posts, preventing pooling and ensuring long-term structural integrity.
Premium Glazing Standard 16mm triple-wall polycarbonate panels provide superior insulation, UV protection, and weather resistance. They are available in clear, bronze, or opal finishes to complement your aesthetic.
Complete Solution Every kit includes all fixings and sealants needed for professional installation—nothing else to source.
Endless Customisation
Order your Evolution Canopy in any colour to match your property or branding. Choose your preferred polycarbonate finish and projection size to suit your space perfectly.
Applications
It is perfect for carports, covered seating areas, covered play areas, porches, patio canopies, caravan covers, and more. The modular design adapts to virtually any requirement.
Posts
- 2.25 metres as standard.
- 3-metre posts are available but at extra costs per post and are viewable through the options.
- Widths 2.5m & 3m - 2 posts
- Widths 3.5m - 6m - 3 posts
- Width 7m - 4 posts
Delivery Times
How Long Does a canopy carport take to deliver? Most Evolution canopies are manufactured and delivered in approximately ( delivery 6-8 weeks)
Technical Information
| Wall Plate | 115 mm High | 70 mm Wide |
| Eaves Beam | 115 mm High | 80 mm Wide |
| Edge Bar | 80 mm High | 30 mm Wide |
| Main Bar | 60 mm High + 3 mm Top Cap | 50 mm Wide |
| Post | 75 mm X 75 mm |
The Evolution canopy can be made in any size and is free-standing; call for a quote.
Select from 5°, 10°, or 15° pitch when ordering
The evolution canopy is white as standard. Also available in most RAL colours; call for a quote.
Please note:
The 3.1m projection relates to the slope length; therefore, the horizontal projection will vary depending on the selected roof pitch.
More Information
The High-Performance Canopy System
The Evolution Canopy is an exciting new system. Its modern design and clean sight lines make installation easy. In addition, its high structural performance makes it ideal for domestic, DIY, and commercial applications.
This highly versatile system offers a solution for many applications, such as:
- carports
- covered seating areas
- covered play areas
- porches
- patio canopies
- caravan shelters
- cycle shelters
- smoking shelters
- walkway covers
The system can be supplied in modular kit format (please see size matrix) or bespoke sizes and configurations.
For specific non-standard projections, please contact us for technical support.
The kits have all the fixings and sealants required for a standard installation and include a comprehensive fitting guide.
System Features
- The system is manufactured in maintenance-free powder-coated aluminium, white as standard. Any RAL number colour is available at extra cost and lead time.
- The canopy is glazed with 16mm triple-wall UV-stabilised polycarbonate sheeting, which offers greater flexibility in canopy design and enhanced strength and rigidity. It is available in clear, bronze, or opal tints.
- The standard canopy range is available on a 15 - 30 working day lead time.
- The eaves beam doubles as an integral box gutter, utilising the support posts as downpipes. Rainwater exits through the variable-height post feet.
- The system can accommodate pitches from 5 degrees to 15 degrees. On standard modular kits, the maximum projection is achieved at a pitch of 5 degrees.
- In addition to the standard lean-to configuration, the system can be specified as a gable roof design with the wall plates bolted back-to-back to form a ridge supported between two host walls or as a free-standing option supported on posts.
Installation Guide - Read More
Free Shipping Terms:
Free shipping is available for deliveries to mainland UK addresses only. This excludes the Scottish Highlands and other remote areas. We reserve the right to refuse delivery to any address at our discretion.
| Dimension | |
| Length of Slope (mm) | 3100mm |
| Length against back wall (mm) | variable 2.5m - 7m |
| Post Height options | 2.25m standard / upgradable to 3m |
| Roof Pitch options | 5, 10, or 15 degrees |
| Min clear height above wallplate | 0 |
| Design | |
| Panel Material & Thickness (mm) | 16mm Polycarbonate |
| Panel Colour options | Clear, Opal, Bronze |
| Frame Colour Options | White / other RAL colours available on application |
| Cantilever / post supported | Post Supported |
| Number of posts | Widths 2.5m & 3m - 2 posts Widths 3.5m - 6m - 3 posts Width 7m - 4 posts |
| Guttering | Integral |
| Delivery Times | |
| Delivery Times | 10 - 20 working days |
