- Stock: In Stock
- Model: DVBEC1-each
- SKU: DVBEC1
- MPN: DVBEC50
More from this brand
Batten End Clip - Universal Dry Verge - 50 Pieces
Universal - can be used on left and right-hand verges
Available in grey and brown
Manufactured from UV stable high-quality polypropylene.
Quick and easy installation via the fast ‘flex and clip’ method
No special tools are required so ideal for rapid refurbishment work.
Quick easy fit starter unit.
All-weather installation.
Verge Wizard has a unique modern design - it is sleek and stylish, solid and robust - practically maintenance-free.
Mechanically fixed
Accommodates gutter systems
Manufactured in the UK to high-quality standards in a modern, efficient factory.
Meets current building regulations
Batten gauge range 260 - 355mm
Roof pitch range 15 - 55 degrees
Newbuild – ensure tiling battens are extended 35mm beyond the gable wall or bargeboard. Fix a batten end clip to the end of every batten using a 40mm (min) x 3.25mm ring shank nail or equivalent screw.
Refurbishment – it is recommended that all existing mortar is removed. Run a suitable batten from eaves to ridge, below the under cloak on the gable wall or directly to the bargeboard.
For each successive Verge Wizard simply flex and clip over the verge below and slide up to the tile toe. Fix into position through the batten end clip or running batten depending on your project. Continue this process until you reach the ridge.
